GH1 with PL mount (and anamorphics)

Hunter Hampton

Hunter Hampton

Carbonite Member
Finally my PL mount showed up. Now I can use my anamorphics! Here is my take on a digital directors viewfinder. Sorry, I got excited!


Attachments

  • P1020095.jpg
    101.1 KB · Views: 0
  • P1020096.jpg
    101.6 KB · Views: 0
  • P1020097.jpg
    102.5 KB · Views: 0
  • desqueesed 2.jpg
    desqueesed 2.jpg
    153.2 KB · Views: 0
  • desqueesed 1.jpg
    desqueesed 1.jpg
    111.1 KB · Views: 0
AAWWWw MANNN!!!! You just answered one of my thoughts. Please...footage please. This camera is scary!!!

Wow awesome.

Very very very very bitchin hunter!

Hunter is that a Lomo 2x Anamorphic? If so are you cropping the sides? Seriously you need to get your hands on some of the Hawk 1.33x lenses ( rental of course ). They are sweet. With the 16x9 sensor coupled with
a 1.33x Hawk, you get 2:37:1......

The PL mount looks well machined. Is this going to be a marketed adapter? If so ,holy-S, this is going to lead things to a whole new level. PL mount on a 1,500 dollar camera, unheard of. Greatness indeed!

.
Pappas

Last edited:
you didn't crop anything in post did you? i think with the RED, not absolute here, that you have to shoot in 3k and crop the rest in post.

Yeah you have to crop a bit of the sides, you need a ~1.2:1 aspect sensor when shooting 2x anamorphics to get the proper "2.35:1" (2.39:1) image. If you dont crop you end up with a 3.56:1 ULTRA WIDE aspect when shooting 16:9.

About footage; I will try to shoot something more substantial than test footage and then post it.

PappasArts said:
The PL mount looks well machined. Is this going to be a marketed adapter? If so ,holy-S, this is going to lead things to a whole new level.
Click to expand...

I think its just the first run of it, I am going to give the maker feedback on how to make it better for the GH1. Its about $350- not my project at all, just a smart guy I bought the lenses from.

hunter richards said:
Yeah you have to crop a bit of the sides, you need a ~1.2:1 aspect sensor when shooting 2x anamorphics to get the proper "2.35:1" (2.39:1) image. If you dont crop you end up with a 3.56:1 ULTRA WIDE aspect when shooting 16:9.

About footage; I will try to shoot something more substantial than test footage and then post it.
Click to expand...



Hopefully you can get your hands on some 1.33x Hawks for trial, no cropping needed.

The math: 1.33xAna X 1.78( 16x9 sensor ) = 2.3674 > round up > 2.3700 = 2.37.1


Of course, I have never seen 3:56:1, how does look? Does the video hold up? That could be some sort of special kinda look for some projects.. Crazy panoramic stuff..

Crazy. Like putting 18" alloy wheels on a VW bug.
If we're going to PL and anamorphic land, I would hope anyone who comes out with a commercial PL adapter for this little wonder builds it to a tolerance where we can back focus and account for any discrepancies in focus mark calibration. Not likely to happen but it looks like a fun project.

A set of hawks would be in excess of $250,000, I dont think I can afford the rental on that- which is why I bought the LOMOs. ; )

3.56:1 is a VERY VERY wide screen look. A little too wide if your not just shooting landscapes. I do like 3:1 quite a but though.

Its actually a Leica M- PL adapter (there is a lecia M - m4/3 adapter behind it) I am going to recommend that he just makes a strait up m4/3 adapter.

hunter richards said:
A set of hawks would be in excess of $250,000, I dont think I can afford the rental on that- which is why I bought the LOMOs. ; )

3.56:1 is a VERY VERY wide screen look. A little too wide if your not just shooting landscapes. I do like 3:1 quite a but though.
Click to expand...

Not to own, just to rent. I don't know your rental house's in your area, however in LA there are a few you can go to and load up a camera for testing. That would be awesome to see on that little guy.

Maybe we can get some of the AIG/stimulus money and get some Hawks........ :)

That flare looks really buff. When RED first announced that they were going to produce a pocket camera, this is kind of what I imagined.

are you trying to disguise your camera with the black tape over the lumix , GH1 and HD symbols or are you just pretending your G1 is a GH1 to feel good???? :shocked:
:D
