I'm So Smart

GenJerDan

GenJerDan

Veteran
With all the talk about the delicateness of the firewire connection, I made this:



Crummy photo, but...simple idea.

Just a piece of aluminum stock with some holes drilled in it. Mounts where the mic mount would be if I was silly enough to use a mic on the camera. 4 more holes for cable ties to secure the firewire cable. (Or that + the mic cables or whatever)

Dan

Re: I'm So Smart

So what are the two small black wires that appear to be running down from the hot shoe on top down behind the rubber firewire cover?

Re: I'm So Smart

That is a good idea. Did you design it because you use DVRack on set?

Re: I'm So Smart

[quote author=Sirius_Doggy link=board=Links;num=1108914975;start=0#3 date=02/20/05 at 10:33:28]So what are the two small black wires that appear to be running down from the hot shoe on top down behind the rubber firewire cover?[/quote]

Um...black elastic string, actually. Attached to the mic covers and the lenscap.

Guaranteed I'd lose them, otherwise. ::)

Dan

Re: I'm So Smart

[quote author=TC link=board=Links;num=1108914975;start=0#4 date=02/20/05 at 12:03:08]That is a good idea. Did you design it because you use DVRack on set?[/quote]

Yep. 25' foot firewire cable, too.

I think I'll go out tomorrow and get some aluminum angle stock and make the thing more like a shelf. The mic cables might need a bit more room, if I attach them, too.

Maybe figure out a quick-release for the whole thing.

Dan

Re: I'm So Smart

good Idea. I have the same firewire cable. NewEgg?
I usually just run the firewire cord throught the velcro strap, it works just like your little firewire tie, but is already built in. :D

Re: I'm So Smart

Yep, NewEgg. Got the 25' and the 16', just in case I get tired of tripping over the 25'. ;)

I think there might be toio much play in the velcroed handgrip. With this thing, I could swing the cam around by the cable and not jostle the connector.

Not that I'd do something like that, even for a very cool effect.

Dan

Re: I'm So Smart

ok i'm glad someone is ahead of me on this, i am doing a LOT more stuff lately where i wish i could use the dv rack and having had my firewire port blown already on my dvx i'm paranoid...

i would like to make something a lot like this but with just a velcro strap running vertically so it could be quick disconnected.

i've been looiking for right angle cables that are 4 pin and preferably 15-25 feet.

where did you get that 4 pin right angle? i've only found 6, no 4-4's

matthew

Re: I'm So Smart

Well...made the one with the angle aluminum. And even painted it. :)

Photo in the orginal post has been updated.

Dan

Re: I'm So Smart

If I had enough cables running at once to make a thick bundle, I'd just run 'em through the supplied mic mount, but...

Dan
